E-BIKE SPECS
|
LT7 |
|
| Frame Type |
6061 Aircraft Grade Aluminum Alloy |
| Frame Style |
Step-Thru Easy Low Mount |
| Motor |
48V 500W (960W Peak) |
| Torque |
65 Nm. |
| Battery |
LG 48V 624Wh (13Ah) Lithium-Ion |
| Est. Range |
110km |
| Controller |
48V 20A Smart Controller |
| Throttle |
Thumb Throttle |
| Pedal Assist |
3 Modes + 5-Level Intelligent Pedal Assist |
| Display |
G51 LCD |
| Headlight |
48V 10W 120 Lux LED Headlight |
| Tail Light |
Yes |
| Turn Signals |
No |
| Brake Light |
Yes |
| Charger |
54.5V 2A Smar Charger |
| Gear System |
Shimano TY200D |
| Gear Shifter |
Shimano TX50 |
| Suspension |
Front Hydraulic Suspension |
| Cassette |
Shimano TZ5007 |
| Pedals |
Aluminum Alloy |
| Brakes |
Logan Hydraulic Disc |
| Brake Rotors |
180mm Stainless Steel |
| Tires |
27.5" x 2.6" |
| Stem |
Adjustable |
| Weight |
62lbs |
| Payload |
350lbs |
| Rider Height |
5'3" - 6'2" |
GEOMETRY
| Total Length | 75.6" |
| Wheel Base | 46.5" |
| Chain Stay Length | 15.7" |
| Standover Height | 18.5" |
| Top Tube Length | 24.4" |
| Head Tube Length | 4.7" |
| Handlebar Length | 26.8" |
| Min Seat to Ground | 35.4" |
| Rider Height | 5'3" - 6'2" |
