| Bike Type |
Lightweight Step-Through E-Bike |
| Motor |
Bafang G210 48V Brushless Rear Hub Motor |
| Motor Power |
500W |
| Maximum Torque |
60 Nm |
| Battery |
48V 12.8Ah Lithium-Ion |
| Battery Capacity |
614 Wh |
| Battery Type |
Semi-Integrated, Removable |
| Pedal Assist Sensor |
Bafang Torque Sensor |
| Pedal Assist Levels |
5 |
| Throttle |
On-Demand Thumb Throttle |
| Display |
Bafang DP C010 Color TFT LCD |
| Display Features |
Bluetooth Connectivity, Built-In Navigation |
| Navigation App |
Bafang Go |
| Charger |
AIMA 48V 3A Fast Charger |
| Estimated Charge Time |
Approx. 5 hours |
| Estimated Range – PAS 1 |
Up to 90 km |
| Estimated Range – PAS 2 |
Up to 80 km |
| Estimated Range – PAS 3 |
Up to 70 km |
| Estimated Range – PAS 4 |
Up to 60 km |
| Estimated Range – PAS 5 |
Up to 50 km |
| Frame |
Lightweight Step-Through Hydroformed Aluminum Alloy |
| Frame Construction |
Integral Smooth Welding, Internal Cable Routing |
| Fork |
Lightweight Rigid Aluminum Fork |
| Stem |
Forged Alloy, Adjustable Angle |
| Handlebar |
City Riser, 680 mm, Ø31.8 mm |
| Grips |
Comfort Ergo, Bolt-On |
| Saddle |
Comfort Saddle |
| Seatpost |
Alloy, Ø30.4 mm, Quick Release |
| Drivetrain |
Shimano 8-Speed |
| Shifter |
Shimano Acera ST-M315 Rapidfire |
| Rear Derailleur |
Shimano Altus RD-M310 |
| Chainring |
46T Direct Mount Alloy |
| Cassette |
Shimano HG Megarange 12–32T |
| Chain |
PYC 1/2" × 3/32" |
| Pedals |
Alloy, 9/16" |
| Brakes |
Tektro HD-E3520 Hydraulic Disc |
| Brake Rotors |
203 mm Stainless Steel |
| Brake Cut-Off |
Yes, Power Cut-Off Sensor |
| Wheels |
27.5", 36H Double-Wall Alloy |
| Tires |
27.5" × 2.1" E-Bike Rated |
| Tire Features |
Reflective Side Strips |
| Front Hub |
Alloy, 100 mm, Bolt-On |
| Spokes |
12G Stainless Steel, Black |
| Front Light |
Integrated White LED, 600 Lumens |
| Rear Light |
Integrated Red LED |
| Brake Light |
Active Rear Brake Lighting |
| Turn Signals |
Integrated Rear Yellow Turn Signals |
| Horn |
Electronic Horn |
| Turn Signal Controls |
Handlebar Thumb Controls |
| Fenders |
Full-Length Fenders Included |
| Kickstand |
Direct-Mount Alloy Kickstand |
| Listed Weight |
55 lb / 25 kg |
| Maximum Payload |
320 lb / 145 kg |
| Frame Style |
Step-Through |
| Connectivity |
Bluetooth |
| Smart Features |
Navigation, Connected Display |
| Safety Certification |
UL-Certified Power System |
| Motor/System Brand |
Bafang |
| Recommended Use |
Urban Commuting, Recreation, Bike Paths & Everyday Riding |
