SPECIFICATIONS

Certification: UL 2849

Frame: Unique Lightweight Step-Thru Hydroformed Aluminum alloy frame, Integral Smooth Welding, Internal Cable Routing,Oversized Taper Headtube with integrated bearings, 83mm BSA, Replaceable forged alloy derailleur hanger,Fully Integrated rear Dropouts with LED Rear light / Brake / Turn Signal lights (remotely controled)

Fork: SR Suntour Mobie A32, 75mm travel Suspension Fork, Locking Lever, Spring Preload Adjustment, Oversized Taper Steerer, 100x15mm Thru-Axle

Stem: Forged Alloy, Adjustable Angle, 1-1/8” Threadless, with Integrated Front Light Mount

Handlebar: City Handlebar, Riser, Ø31,8mm, Width: 680mm

Grips: Comfort, Retro Inspired

Seatpost: Alloy, Ø30.4mm Quick Release clamp

Saddle: Comfort Wide Retro Inspired Brown, Tear-Resistant, Integrated Springs and Lifting Handle

Shifters: Shimano Acera ST-M315, Rapidfire, 8 Speeds

Derailleur: Shimano Altus RD-M310, with Protecting Cage

Chainring: Direct Mount, Splined alloy spider, 52T

Cassette: Shimano HG, Megarange 11-34T

Chain: PYC, 1/2” x 3/32”

Pedals: Sure Grip Platform, Alloy, 9/16’’

Brakes: Tektro HD-E3520, Hydraulic Disc Brakes,with Power cut-off sensor

Rotors: Stainless Steel TR-52 Anti Vibration 203mm 6-Bolt rotors

Rims: 27.5’’, 36H, MTB-grade Disc specific double wall profile, Schrader

Hubs: Front: Alloy, 100x15mm Thru-Axle, Sealed Bearings, 6-Bolts Disc MountRear: (See Motor)

Spokes: 13G Stainless Steel, Black

Tires: Chao Yang, 27.5 x 2.6’’, Retro Tan Wall,Reflective Side Strips, E-Bike Rated Casing

Driving Lights: Front: Semi-Integrated white driving light, 600 lumens, Connected to battery Rear: Integrated red driving light / Active braking and Yellow turning signal lights (remotely controlled)

Accessories: SureFix System Full-wrapping Fenders, Direct Mount Alloy E-Bike rated Kickstand

Listed Weight: 64 lbs (29 kg)

Max Payload: 400 lbs (180 kg)

PEDAL ASSIST SYSTEM

Motor: Bafang G0270 48V Brushless Rear Hub, 500W OR 750W Nominal, 1100W Peak

Battery: Bafang BT F400, 720Wh Capatity Lithium-ion, High Performance LG cells UL CERTIFIED

Display: Bafang DP C270.CAN New Generation Smart Color Backlit LCD, G5.4, IP65 Connector

Sensor: Bafang SR PA242 Torque Sensor, JIS Bottom Bracket, BSA External Cups

Throttle: On Demand Thumb Throttle

Controls: Left Side: Power / PAS level / Driving Lights Right Side: Blinkers Turn Signal Lights / Electronic Horn

Charger: AIMA 48V Fast Charge

Charge Time: Approx. 5 hours
