SPECIFICATIONS
Battery: 48V 17.5Ah + Optional Secondary Battery
Range: 150km (48V 17.5Ah LG Cells + FREE Second Battery 14Ah)
Motor: 48V1000W Bafang M620 mid motor with 160 N.m torque
Total Payload Capacity: 300 lbs
Recommended Rider Heights: 5'3" ~ 6'4"
Maximum Speed: 45KMH
Charger: US standard 2.0 A smart charger
Controller: 48V 30A
Display:
DP C010.C8 Display (CAN protocol - Safari, Moon black)
DPC18 display (UART protocol - Black, Leaf camo, Army green)
Weight: 88.2 lbs
PAS: 0~5 level pedal assist, torque sensor
Box Dimensions: (cm) 172 L x 35.5 W x 85 H
Tires: KENDA sport tires 26" x 4.0"
Brake lever: HD-E500 Hydraulic disc brakes levers with motor cutoff switch
Rear Light: Taillight
Shifter: SRAM NX 1x11 speed gear shift system
Brake Rotor: 180MM hydraulic disc brakes
Throttle: Thumb throttle
Handlebar: Comfortable stem
Crank: 170mm forged alloy
Cassette: SRAM NX 11-42T
Fork: EUNORAU inverted 140mm travel
Shock: DNM AO-38RC,190mm, Travel 50mm
Saddle: Selle Royal Saddle, Height to Ground 35.0"-42.5"
Pedal: Nylon pedal with reflectors
Frame: Aluminum alloy 6061 full suspension
Front Light: LED light
Tool: Included
Chainring: 40T BAFANG chain-wheel with protection
GEOMETRY & MEASUREMENTS
WARRANTY
2 YEARS! For full warranty details, click here.
