SPECIFICATIONS

Certification:

UL 2849

Frame: Unique Step-Thru Hydroformed Aluminum alloy frame, Integral Smooth Welding, Internal Cable Routing,Integrated bearings, 100mm BSA, Replaceable forged alloy derailleur hanger

Fork: Zoom, 80mm travel Suspension Fork, Locking Lever, Spring Preload Adjustment

Stem: Forged Alloy, 1-1/8” Threadless

Handlebar: Alloy, Riser, Ø31,8mm, Width: 680mm

Grips: Comfort Ergo, Bolt-On

Seatpost: Alloy, Ø30.4mm Quick Release clamp

Saddle: Comfort Wide, Tear-Resistant, Integrated Springs and Lifting Handle

Shifters: Shimano Acera ST-M315, Rapidfire, 7 Speeds

Derailleur: Shimano Altus RD-M310, with Protecting Cage

Chainring: Direct Mount, Splined alloy spider, 52T

Cassette: Shimano HG, Megarange 11-34T

Chain: PYC, 1/2” x 3/32”

Pedals: Sure Grip Platform, Alloy, 9/16’’

Brakes: Tektro HD-E3520, Hydraulic Disc Brakes,with Power cut-off sensor

Rotors: Stainless Steel TR-52 Anti Vibration 203mm 6-Bolt rotors

Rims: 26’’, 36H, Wide Profile, Alloy, Schrader

Hubs: Front: Alloy, 135mm, Bolt-On, 6-Bolts Disc Mount, Rear: (See Motor)

Spokes: 13G Stainless Steel, Black

Tires: 20 x 4.0’’, Retro Tan Wall, Reflective Side Strips, Moped rated!

Driving Lights: Front: Big Headlight, White, 100 LUX, Connected to battery, Rear: Semi-Integrated Red LED driving light, Connected to battery

Included Accessories: Charger, Pedals, Alloy Cargo Rack, SureFix System Full-wrapping Fenders, Direct Mount Alloy E-Bike rated Kickstand

Listed Weight: 82 lbs (37 kg)

Max Payload: 400 lbs (180 kg)

PEDAL ASSIST & ELECTRICAL SYSTEM

Motor: Bafang G0270 48V Brushless Rear Hub, 500W OR 750W Nominal, 1100W Peak

Battery: Bafang BT F400, 720Wh Capatity Lithium-ion, High Performance LG cells UL CERTIFIED

Charge Time: Approx. 5 hours

EST Range: 100km

Display: Bafang DP C271.CAN New Generation Smart Color Backlit LCD, G5.4, IP65 Connector

Sensor: Bafang SR PA242 Torque Sensor, JIS Bottom Bracket, BSA External Cups

Throttle: On Demand Thumb Throttle

Controls: Power / PAS level control pad

Charger: AIMA 3 Amp Fast Charger

MEASUREMENTS & GEOMETRY

WARRANTY
